Improved Stochastic Progressive Photon Mapping with Metropolis Sampling

Loading...
Thumbnail Image
Date
2011
Journal Title
Journal ISSN
Volume Title
Publisher
The Eurographics Association and Blackwell Publishing Ltd.
Abstract
This paper presents an improvement to the stochastic progressive photon mapping (SPPM), a method for robustly simulating complex global illumination with distributed ray tracing effects. Normally, similar to photon mapping and other particle tracing algorithms, SPPM would become inefficient when the photons are poorly distributed. An inordinate amount of photons are required to reduce the error caused by noise and bias to acceptable levels. In order to optimize the distribution of photons, we propose an extension of SPPM with a Metropolis-Hastings algorithm, effectively exploiting local coherence among the light paths that contribute to the rendered image. A well-designed scalar contribution function is introduced as our Metropolis sampling strategy, targeting at specific parts of image areas with large error to improve the efficiency of the radiance estimator. Experimental results demonstrate that the new Metropolis sampling based approach maintains the robustness of the standard SPPM method, while significantly improving the rendering efficiency for a wide range of scenes with complex lighting.
Description


@article{
:10.1111/j.1467-8659.2011.01979.x
, journal = {Computer Graphics Forum}, title = {{
Improved Stochastic Progressive Photon Mapping with Metropolis Sampling
}}, author = {
Chen, Jiating
and
Wang, Bin
and
Yong, Jun-Hai
}, year = {
2011
}, publisher = {
The Eurographics Association and Blackwell Publishing Ltd.
}, ISSN = {
1467-8659
}, DOI = {
/10.1111/j.1467-8659.2011.01979.x
} }
Citation
